| Item |
Unit |
S260 / 1500 |
S260 / 2000 |
S300 / 2000 |
S300 / 2500 |
| Screw L/D Ration |
L/D |
25 |
25 |
25 |
25 |
| Screw Diameter |
mm |
75 |
80 |
80 |
90 |
| Injection pressure |
kgf/cm² |
1280 |
1125 |
1400 |
1106 |
| Injection volume |
cm³ |
1414 |
1608 |
1810 |
2290 |
| Shot weight (PET) |
g |
1654 |
1882 |
2117 |
2680 |
| Shot weight |
oz |
58 |
66 |
75 |
95 |
| Clamping force |
T |
260 |
260 |
300 |
300 |
| Clamping Stroke |
mm |
540 |
540 |
585 |
585 |
| Max/Min Thickness of mold |
mm |
200 - 580 |
200 - 580 |
300 - 720 |
300 - 720 |
| Space Between Tie Bars (W*H) |
mm |
570 * 570 |
570 * 570 |
660 * 760 |
660 * 760 |
| Ejector Stroke |
mm |
150 |
150 |
180 |
180 |
| Ejector Force |
T |
8 |
8 |
20 |
20 |
| NO.of Ejector Pins |
pcs |
5 |
5 |
5 |
5 |
| Max system pressure |
kg/cm² |
160 |
160 |
160 |
160 |
| Motor Power |
kw |
36 |
36 |
44 |
44 |
| Heater Input Capacity |
kw |
32 |
36 |
36 |
44 |
| Machine Size (L*W*H) |
cm |
700 * 200 * 220 |
7000 * 160 * 220 |
800 * 200 * 220 |
800 * 210 * 220 |
| Machine Weight |
T |
12 |
12 |
14 |
14 |
| Notice: Demark reserve the rights to make any product improvement or specification change without prior notice. |
* Demarkは製品を変更する権利を留保し、仕様は予告なしに変更される場合があります。
